GIGABYTE Pulse 550W SMPS
- 80 Plus Bronze certified to deliver >82% efficiency to save energy.
- Complies with Intel ATX +12V V2.31 power supply design guide.
- Extended sleeved cable to offer greater flexibility in high-end and high performance chassis.
- Single +12V rail offers greater compatibility with all the latest components.
- Industrial power supply protection ready: Over Power Protection, Over Voltage Protection, Short Circuit Protection and Under Voltage Protection provide maximum safety to your critical system components.
| Model | |||||
| GZ-EFS55A-C3 | |||||
| Dimension | |||||
| 140 x 150 x 86mm | |||||
| Connectors | |||||
| 20+4pin Motherboard Connector | 1 | ||||
| 4+4pin +12V CPU Connector | 1 | ||||
| 6+2pin PCI-E 2.0 Connector | 3 | ||||
| SATA Connectors | 6 | ||||
| 4pin Peripheral Connectors | 4 | ||||
| 4pin Floppy Connector | 1 | ||||
| Weight | |||||
| 1.77 kg | |||||
| Info | |||||
| AC Input | 100-240VAC, 10-5A | ||||
| DC Output | +5V | +3.3V | +12V | -12V | +5VSB |
| Max Output Current | 20A | 20A | 45.5A | 0.5A | 2.5A |
| Max Combined Wattage | 100W | 546W | |||
| 550W | |||||
| Certifications | |||||
| 80Plus Bronze | |||||
| Safety Approval | |||||
| CB, CE, CCC, EAC, TUV | |||||
| * The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice. | |||||
| * Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration. | |||||
| * All trademarks and logos are the properties of their respective holders. | |||||
| * Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount. | |||||
